TOTAL Digital Multimeter TMT5310002: Precision Measurement in Your Palm
Overview
The TOTAL Digital Multimeter TMT5310002 is a True RMS digital multimeter designed for accurate and reliable electrical measurements. Whether you’re a professional electrician, technician, or DIY enthusiast, this tool offers a wide range of functions in a compact, user-friendly design—perfect for diagnostics, troubleshooting, and routine testing.
Key Features
- Display: True RMS, 6000 counts
- Voltage Measurement:
- DC: 600mV / 6V / 60V / 600V / 1000V (±0.5% +3)
- AC: 600mV / 6V / 60V / 600V / 750V (±0.8% +5)
- Current Measurement:
- DC: 600μA / 6mA / 60mA / 600mA / 10A (±1.2% +3)
- AC: 600μA / 6mA / 60mA / 600mA / 10A (±1.5% +3)
- Resistance: 600Ω to 60MΩ
- Capacitance: 10nF to 100mF
- Frequency: 10Hz to 10MHz
- Duty Cycle: 1%–95% (±3.0% +3)
- Diode Test and Continuity Check
- Non-Contact Voltage Detection (NCV) with live/neutral line identification
- Max/Min Recording and Data Hold Function
- Backlight and Flashlight for low-light environments
- Low Battery Indicator and Input Jack LED Alerts
Design and Usability
- Power Supply: 3 Ă— LR03 AAA batteries (included)
- Dimensions: 16 Ă— 24 Ă— 5 cm
- Weight: Approx. 1kg
- Packaging: Double blister for protection and display
The multimeter’s intuitive layout, bright backlit display, and rugged build make it ideal for both fieldwork and bench testing.
Why Choose the TMT5310002?
TOTAL’s TMT5310002 offers a powerful combination of accuracy, safety, and versatility. Whether you’re measuring voltage in a control panel or checking continuity in a circuit board, this Digital Multimeter delivers dependable results every time.
